Acid Plant Database  February 11, 2021

Owner Ambatovy



10 km south of Tamatave


40%    Sheritt International Corporation
27.5% Sumitomo Corporation
27.5% Korean Resources Corporation
5%     SNC-Lavalin

Website www.ambatovy.com
Plant Ambatovy Project
Plant No. 1 Plant No. 2
Coordinates* 18° 11' 50" S, 49° 21' 27" E 18° 11' 51" S, 49° 21' 29" E
Type of Plant Sulphur Burning Sulphur Burning
Gas Source Elemental Sulphur – Bulk Elemental Sulphur – Bulk
Plant Capacity 2750 MTPD 2750 MTPD
Emissions - -
Status Operating Operating
Year Built 2010 2010
Technology Noram Engineering and Constructors Inc. Noram Engineering and Constructors Inc.
Contractor Bateman Africa (Pty) Limited Bateman Africa (Pty) Limited
Remarks - -

Junye (China): Acid tower, sulphur furnace, cold interpass HX, pump tank, stack
Metso ND (South Africa): Converter
Sinopec Nanjing Design Institute (SNDI) (China): Waste heat boiler, economiser, superheater, de-superheater

Dimensions: Diameter = 14.5 m, Height = 24 m

Pictures Ambatovy-Site-1.jpg (158504 bytes)  Ambatovy-Site-2.jpg (160212 bytes)  Ambatovy 3.jpg (167289 bytes)  Ambatovy-8.JPG (59149 bytes)  Ambatovy-13.jpg (16270 bytes)  Ambatovy-12.jpg (124849 bytes)  Ambatovy-10.JPG (50028 bytes)
